How to Remove a Broken Bolt

When a damaged bolt becomes lodged in a crucial piece of machinery or equipment, it can be an annoying hindrance.  However, you may effectively and safely remove a damaged bolt without inflicting more harm if you have the correct tools and methods.  Here is a detailed tutorial to assist you in resolving this frequent issue.

1. Assess the Situation

Before attempting to remove the broken bolt, determine its location, size, and how much of it is protruding. If part of the bolt is still exposed, the removal process will be easier compared to a fully embedded bolt.

2. Gather the Necessary Tools

Depending on the severity of the break, you may need:

- Pliers or vice grips

- Penetrating oil (e.g., WD-40)

- Left-handed drill bits

- Bolt extractor set

- Tap and die set

- Heat source (blowtorch)

- Hammer and center punch

3. Apply Penetrating Oil

Spray a generous amount of penetrating oil onto the bolt and let it sit for at least 15–30 minutes. This will help loosen rust and debris, making removal easier.

4. Use Pliers or Vice Grips

If a portion of the bolt is still protruding, try gripping it tightly with pliers or vice grips and gently twisting it counterclockwise. If it doesn’t budge, move to the next step.

5. Use a Left-Handed Drill Bit

A left-handed drill bit rotates counterclockwise, which may help loosen the bolt as you drill.

- First, use a center punch to create a small dent in the bolt to guide the drill bit.

- Slowly drill into the center of the bolt using the left-handed bit.

- If the bit catches, it may unscrew the bolt automatically.

6. Try a Bolt Extractor

If the drill bit doesn’t work, use a bolt extractor:

- Drill a small hole in the center of the broken bolt.

- Insert the extractor and turn it counterclockwise using a wrench.

- Apply steady pressure but avoid excessive force to prevent breaking the extractor.

7. Apply Heat (If Necessary)

If the bolt remains stuck, apply heat using a blowtorch to expand the surrounding metal. Be cautious not to overheat or damage nearby components.

8. Tap and Die Method

If the bolt is deeply embedded, you may need to rethread the hole using a tap and die set after removing any remaining fragments.

9. Prevent Future Bolt Breakage

To avoid broken bolts in the future:

- Use anti-seize lubricant when installing bolts.

- Avoid overtightening.

- Use high-quality bolts suitable for the application.

- Regularly inspect and replace worn bolts before they fail.

In conclusion

It takes time and the proper equipment to remove a broken bolt.  These procedures can assist in properly removing the bolt without causing harm to the surrounding material, whether you choose to use penetrating oil, drilling, or an extractor.  The best course of action might be to get expert help if the bolt is extremely difficult to remove.
